Printer unit
● Gear enclosed spray lubrication system, keyless drive design, so that accurate long-term chromatic unchanged. High-speed Ink Printing Slotting Machine Manufacture.
● Frequency control system to control becomes easy and flexible. Each group of printing unit is equipped with jogging button for easy control and loaded rubber plate.
● Each printing unit can be electrical separation. Printing Slotting Machine.
● High-precision anilox roller, diameter 195mm. The textured density of anilox roller is 180-300 lines / inch, to ensure the printing effect is clear and beautiful.
● Ink supply system is pneumatic diaphragm pumps, high efficiency, Flexo Printing Slotting Machine saving ink. Automatic cycle supply. Cleaning with clean water can be.
● Automatic uniform system to keep the anilox roller quit. When the machine stop,the anilox roller and rubber roller could running independently for transmission ink and prevent the ink dry out.
● The rubber roller is use high quality hard wearing rubber,and with the middle of a relatively high high-precision grinding. Semi Automatic Carton Flexo Printing Slotting Machine.
● Phase institutions is 360-degree Electric adjustment, ergonomic design.
Slotter unit
● Gear enclosed spray lubrication system, keyless drive design, so that accurate long-term chromatic unchanged. High Speed Flexo Printing Slotting(stacking Unit)
● Phase institutions is 360-degree Electric adjustment, ergonomic design
● Four-blade sync adjustment for carton height.
● Serrated slotted cutter. Thickness: 7mm. Cutting angle blade width: 40mm.
Die Cutting Part
● Die cutting roller for the high quality steel materials,30mm thickness, balance correction, hard-chrome plating
● Wallboard for high-quality cast iron material,50mm thickness, and large processing center production.
● Soft-roll automatic grinding institutions to pouches repeat usage,grinding3-4times;
● Line speed automatic compensation to ensure that each batch of cardboard boxes full of die-size line;
● Use Imported Polyurethane soft rubber, ease of installation, can cut 12000000 times.;
● Mechanical soft roll about 40 mm lateral movement ,the pads wear uniform;
● 40cr material the use of grinding gears for 6,low noise long life;
● Die cutting roller cylinder automatic separation devices to reduce wear pouches.
Specification:
Model | YKB-1424 |
Roller diameter | 450mm |
Speed p/min | 0-60 |
Max board size mm | 1400x2400 |
Max print area mm | 1400x2200 |
Print plate thickness | 5-9mm |
Overprint error | ≤ ± 0.5 mm |
Cardboard | 3/5/7 layers |
